(6.5m x 2.3m) Large Flat Pack Office
The all new large 6.5m flat pack office is here and available for sale / delivery.
We are sure you will be impressed with this unique product. This is the only 20ft cabin on the market that is completely man-portable.
Large Flat Pack Office Cabin Features
- Size: 6.5m x 2.3m
- DIY assembly
- No cranes necessary
- No specialist tools required to build
- Fast assembly time
- Robust but lightweight construction
- Ideal for inaccessible areas
- Can be stacked Link cabins together to form larger spaces
- Fully insulated
- Galvanized steel construction
- Vinyl floor covering
- 2 x double glazed windows
- Electric pack available
- Window guards available
- Stacking kit available
- Colour: White (RAL9002)
PRODUCT SPECIFICATIONS
| External Length (m) | 6.51 |
|---|---|
| External Width (m) | 2.31 |
| External Height (m) | 2.35 |
| Internal Length (m) | 5.90 |
| Internal Width (m) | 2.19 |
| Internal Height (m) | 2.15 |
| Door Width (m) | 0.79 |
| Door Height (m) | 1.97 |
| Height (Flatpacked) (mm) | 450 |
| Length (Flatpacked) (m) | 6.5 |
| Width (Flatpacked) (m) | 2.31 |
| No. of Windows | 2 |
| Weight (Flatpacked) (kg) | 1300 |
| Weight Heaviest Part (when Demounted) (kg) | 74 |
| Floor Type | 18mm Marine Plywood |
| Floor Loading | 250kg/m2 evenly distributed |
| Internal Floor Covering | 2mm PVC Linoleum (flash point B1 difficult to burn, smoke density Q1) |
| Internal Wall Covering | 0.60mm galvanised steel electrostatic powder coated in RAL9002 |
| Insulation | 50mm EPS insulation |
| Electrical Requirements. (Amps) | 32amp |
